Dik Geurts Instyle 800EA

Dik Geurts Instyle 800EA

80 cm wide wood fire insert

The Instyle 800 EA, with a width of 80 cms, can be installed into a standard UK brick chimney or pre-fabricated chimney as a widescreen wood burning fire.  It has a heat output range from 8 - 12 kW and an impressive energy efficiency rating of 77%.  Furthermore, it has DEFRA approval for use in UK urban smokeless zones.

Dik Geurts Instyle 800EA Specifications

Brand Dik Geurts
Series Instyle/Prostyle
Category Wood fires
Energy efficiency class A
Model Built-in, Insert
Fire view Front
Shape Horizontal
Fuel Wood
Combustion system Open combustion
Door type Hinged door
Control Manual control
Colours Dark anthracite
Material Steel
Interior Vermiculite natural
Output net min.  (kW) 8.0
Output net max.  (kW) 12.0
Max.  log length (cm) 50
Efficiency (%) 76.6
Consumption wood max (kg/h) 2.9
CO emission (%-13% O2) 0.06
NOx emission (mg/Nm3-13% O2) 122
Built-in depth (mm) 400
Fire view width (mm) 660
Fire view height (mm) 437
Weight (kg) 130
Flue top (mm) 180
External air connection Optional
